24V DC Conventional UV Flame Detector

Home > Products > Conventional

Description

This UV flame detector uses the best flame sensor. It has sensitive response and large detection angle, and it is consistent and long-term stable and reliable.
The red LED indicators on the flame detector provide local 360° visual alarm indication. They flash every 5 seconds to indicate the detector is on and is working. When a flame is detected, the fire alarm will be triggered, the red LED indicator will be on, and the buzzer will make a loud alarm sound.
The test button is used to test whether the detector works normally. Each time the button is pressed, the buzzer will beep once and the red LED indicator will flash. During fire, the test button can be used to reset silence. This product is 4-wire system, using relay output.
UV Flame Detector Features:

Easy to install, including mounting bracket
Highly sensitive sensor, high-quality and durable
Has alarm sound louder than 85dB@3m
Local 360° visual alarm indicator
Excellent reliability and stability
Suitable for homes and other places where flame detection is required
Complies with all requirements of the latest EN54-10 standard

Neat appearance, large detection angle

UV Flame Detector Technical Parameters

Operating Voltage	Voltage 24V DC
Operating Current	Monitoring status≤3mA Alarm status≤30mA
Spectrum	185-260nm
Sensitivity	Grade 1
Detection Angle	≤120°
Relay Contact Capacity	1A@24V DC
Alarm SPL	≥85dB @3m
Operating Temperature	-10℃～50℃(14~122°F) 5% to 95% RH (non-condensing)
Application	For indoor use only
Standard Number Ref	EN54-10
Materials and Color	ABS, white
Size	φ99.8mm*43.2mm (with cover)
Weight	About 120g
Indicator	Normal: Blinking Alarm: Lighting
